NDT Category 01

ULTRASONIC
TESTING

Advanced phased array & TOFD flaw detectors. Precision instruments for weld inspection, thickness gauging, and structural integrity assessment across critical industries.

Explore Products→ Request a Quote

4MHz

Probe
Frequency

0.1mm

Thickness
Resolution

Featured Instrument

Phased Array UT Flaw Detector

Full A/B/C scan with DAC/TCG curves

NDT Category 02

MAGNETIC
PARTICLE
TESTING

AC/DC electromagnetic yokes, UV LED torches, and complete MPI bench systems. Detect surface and near-surface discontinuities in ferromagnetic materials with unmatched sensitivity.

Explore Products→ Request a Quote

365nm

UV Peak
Wavelength

4.5kg

Min Lifting
Power

Featured Instrument

MPI Yoke + UV LED System

ASTM E709 / ASME Sec V compliant

NDT Category 03

DIMENSIONAL
PRECISION

Digital & vernier calipers, micrometers, height gauges, and dial indicators. Measure with confidence down to 0.001mm resolution across all critical inspection workflows.

Explore Products→ Request a Quote

0.001

mm Resolution
Micrometers

±0.02

mm Caliper
Accuracy

Featured Instrument

Digital Vernier Caliper Series

IP67 rated, 0–300mm, RS232 output

NDT Category 04

CALIBRATION
BLOCKS
& STANDARDS

IIW Type 1 & 2, V2, DAC, Step Wedge, PAUT blocks and AWS resolution standards. Precision-machined to EN/ASTM compliance for traceable instrument calibration.

Explore Products→ Request a Quote

±0.05

mm Machining
Tolerance

ISO

17025 Traceable
Certificates

Featured Standard

IIW Type 1 Calibration Block

BS 2704 / EN 12223 / ASME Sec V

01 / 04

Leading the way in Non-Destructive Testing solutions.

Precision Beyond the Surface.

Book Now

Authorized distributors for the world's most trusted NDT brands.

Equip for Excellence.

Book Now

Welcome to Vertex Systems

Precision Beyond the Surface.

Advanced NDT Instruments, Equipment, and Integrated Support Services for critical industries.

Welcome to Vertex Systems At Vertex Systems, we understand that structural integrity is non-negotiable. As a premier provider of high-end Non-Destructive Testing (NDT) instrumentation and support services, we bridge the gap between cutting-edge technology and field application. From Ultrasonic Testing (UT) to Radiography and Eddy Current solutions, we ensure your assets meet the highest safety and quality standards.

High-Performance Equipment: Supplying the latest NDT hardware from global leaders.

Calibration & Repair: State-of-the-art laboratory services to keep your instruments precise.

Technical Support: Expert consulting and training for complex inspection challenges.

More About

Get A Solution For All Industries

Specialized Solutions for Critical Industries

Power Generation Application:

Nuclear, Wind, and Thermal plant maintenance. Our Role: Advanced remote visual inspection (RVI) tool

Oil & Gas Application

Pipeline integrity, weld inspection, and corrosion mapping. Our Role: Providing rugged flaw detector

Marine & Infrastructure Application

Hull thickness gauging and bridge structural health monitoring. Our Role: Portable, waterproof, and

Automotive & Manufacturing Application

Quality control for castings, forgings, and machined parts. Our Role: Automated inline testing syste

NDT & Inspection Products

Ultrasonic Testing
Equipment & Systems

Precision instruments engineered for critical flaw detection, thickness measurement, and material characterisation across industrial applications.

Full Range

Ultrasonic Testing

Complete portfolio of ultrasonic NDT solutions — from portable flaw detectors and thickness gauges to specialised probes, cables, and calibration blocks — for aerospace, oil & gas, and structural inspection.

Ultrasonic Flaw Detectors

Portable and benchtop flaw detectors with A-scan, B-scan, and DAC/TCG capabilities for weld inspection and defect characterisation.

View Products

Precision

Ultrasonic Thickness Gauges

High-accuracy digital thickness gauges for corrosion monitoring, pipe wall measurement, and coating thickness on metals and plastics.

View Products

Wide Range

UT Probes

Normal beam, angle beam, dual crystal, and immersion probes across frequencies and element sizes for every inspection scenario.

View Products

Compatible

UT Cables

Lemo, BNC, and LEMO 01 terminated coaxial cables engineered for low signal loss and high shielding in demanding field conditions.

View Products

Standards

Calibration Blocks

IIW Type 1 & 2, V2, step wedge, DAC, and PAUT calibration blocks to ASTM, AWS, and EN standards — fully traceable and certified.

View Products

Essentials

Accessories

Couplants, scanning fixtures, probe holders, carry cases, and ancillary components to complete and optimise your ultrasonic testing setup.

View Products

Who we are

India's trusted source for precision NDT & metrology

Product Depth 70+

From portable ultrasonic flaw detectors and MPI yokes to automated penetrant inspection benches and sub-micron slip gauge blocks — Vertex covers every stage of industrial quality control under one roof. All products are sourced from ISO-certified manufacturers and comply with ASTM, EN ISO, and DIN standards.

Quality & compliance

Every instrument in the Vertex catalogue carries traceable calibration and meets the specific method standards inspectors depend on — IIW, ASTM E165, ASTM E1444, EN ISO 3452, IS/DIN 862, and more. Whether your audit demands NADCAP, API, or ASME compliance, the equipment arrives ready to qualify.

Expert support

The Vertex team brings hands-on NDT expertise to every enquiry — helping customers select the right probe frequency, choose between fluorescent and visible-dye systems, or specify the correct calibration block for their weld geometry. Reach a specialist at +91 73866 87721 or sales@vertexsystems.in, 8 AM – 7 PM IST.

Team Working Dedicatedly

We have 15++ years of experience with providing wide area of specialty services

What We do

Complete NDT Ecosystems. One Partner.

Complete NDT Ecosystems. One Partner. Sub-text: We don't just sell boxes; we provide the lifecycle support your inspection team relies on.

Premium Equipment Supply

Authorized distributors for the world’s leading NDT manufacturers. We supply advanced Ultrasonic, Radiographic, and Eddy Current instruments tailored to your inspection requirements.

ISO/IEC 17025 Calibration

Our state-of-the-art laboratory ensures your instruments meet international accuracy standards. We offer fast-track calibration for UT, MT, PT, and ET equipment with full traceability.

Service & Repairs

Minimize downtime with our component-level repair center. Our factory-trained engineers use genuine spare parts to restore your equipment to original factory specifications.

Rental & Leasing

Project-based needs? Access our extensive fleet of ready-to-use NDT equipment. Flexible daily, weekly, and monthly rental terms to manage your CapEx efficiently.

Magnetic Particle Inspection products from Vertex Systems

Magnetic Particle Inspection

Industrial NDT Testing Solutions

Professional-grade MPI equipment engineered for reliable flaw detection in ferromagnetic materials

Complete Range

Magnetic Particle Testing

Full-spectrum MPI solutions for surface and near-surface defect detection. Trusted across aerospace, automotive, and heavy engineering sectors.

Portable YokesWet BenchesPower PacksUV SystemsAccessories

7 sub-productsASTM / ISO

Portable

MPI Yokes

Lightweight AC/DC electromagnetic yokes for on-site inspection with adjustable pole spacing.

AC / DCPortable

Stationary

MPI Benches / Wet Benches

Horizontal wet bench systems with integrated UV lighting and multi-directional magnetization.

HorizontalWet System

High Power

MPI Power Packs

Heavy-duty DC power supplies delivering stable half-wave and full-wave current for large component magnetization.

DC HW/FW1–10 kA

UV-A 365 nm

UV LED Torches

High-intensity UV-A LED handheld torches delivering ≥1000 µW/cm² irradiance for field inspection.

365 nmLED

Longitudinal

Magnetic Coils

Fixed and flexible magnetizing coils for longitudinal field generation in cylindrical components.

Fixed / FlexLongitudinal

Station Use

UV Inspection Lamps

Bench-top UV-A flood lamps with wide coverage. Compliant with ASTM E1444 and EN ISO 3059.

ASTM E1444UV-A

14+ Items

MPI Accessories

Complete kit — Pie Gauges, Ketos Rings, UVA Meters, Digital Gauss Meters, MPI Chemicals and more.

CalibrationConsumables

Explore full MPI range

Penetrant Inspection Systems — DPT product range from Vertex Systems

Penetrant Testing — DPT / FPI

Detect the invisible

Liquid penetrant inspection systems that reveal surface-breaking defects invisible to the naked eye — from portable field kits to fully automated production lines.

System types

FPI

Fluorescent

ASTM

E165 / E1316

DPT

Visible dye

01 Complete Range

Overview — all systems

Penetrant Inspection Systems

Full-range DPT / FPI solutions covering fluorescent and visible-dye methods, from portable field kits to fully automated multi-station production lines. Compliant with ASTM E165 and EN ISO 3452.

Apply › Dwell › Develop › Inspect

ASTM E165EN ISO 3452FPI + DPT

02 Dual Method

Fluorescent + Visible

FPI & Visible Dye Systems

Dual-method penetrant systems — high-sensitivity fluorescent (UV-A) and white-light visible dye for field-ready inspection without UV equipment.

UV-A FPIVisible DPT

03 3 Automation Tiers

Automation spectrum

Manual / Semi-Auto / Auto Models

Choose your automation tier — hand-operated for R&D labs, PLC-assisted semi-auto for mid-volume, or fully robotized lines for mass production.

ManualPLCRobotic

04 Field Ready

Portable kit

Portable Inspection System

All-in-one carry case with penetrant, developer, cleaner aerosols and UV torch — designed for on-site, in-service, and field inspection of welds and castings.

Aerosol kitOn-site

05 Production

Stationary / production

Bench-Type Stationary System

Multi-tank bench systems with dedicated penetrant, emulsifier, and rinse stations. PLC-controlled with integrated drying oven and UV inspection booth.

3-tankPLCUV booth

06 6 Item Types

DPT accessories

DPT Accessories

Complete DPT support — UV lamps, drying ovens, pressure sprayers, dipping tanks, timer units, inspection trolleys, and penetrant consumables in all grades.

UV lampsOvensChemicals

Explore full DPT / FPI range

Dimensional Measuring Instruments — precision metrology product range

Metrology & Precision

Dimensional Measuring Instruments

Workshop-grade to laboratory-precision instruments for dimensional inspection, quality control, and surface metrology across every manufacturing discipline.

9 Product Categories

01 3 Types

Hero instrument — most versatile

Vernier Calipers

Industry-standard dimensional measurement tools for outside, inside, depth, and step measurements. Available in digital LCD, dial indicator, and traditional vernier analog formats. Hardened stainless steel construction with IP67 protection on digital variants.

Digital LCD Dial Type Analog Vernier Carbon Fibre Stainless Steel

0–600 mm0.01 mmIS / DIN 862

02 3 Types

Sub-micron precision

Micrometers

Screw-thread based precision gauges for Outside, Inside, and Depth measurement. 0.001 mm resolution with digital Digimatic variants available.

0–600 mm0.001 mm

03 Digital / Vernier

Vertical measurement

Height Gauges

Column-based height measurement instruments for scribing, step, and datum-referenced height inspection on surface plates. Digital and vernier scale models.

0–1000 mm0.01 mm

04 DTI / DI

Deflection measurement

Dial Indicators / DTI

Plunger-type Dial Indicators and lever-type Dial Test Indicators for runout, flatness, alignment, and comparative measurement. Magnetic stand compatible.

0.001 mmPlunger / Lever

05 Internal

Internal diameter

Bore Gauges

Two-point and three-point bore gauging systems for measuring cylinder bores, bushings, and holes. Self-centering anvil design for accurate readings.

2-point / 3-pointØ6–600 mm

06 Gap / Thread

Gap & thread inspection

Feeler & Thread Gauges

Hardened steel feeler blade sets for gap and clearance measurement. Thread pitch gauges in metric (M), UN, and Whitworth profiles for form verification.

0.05–5 mmM / UN / BSW

07 Granite / CI

Reference datum surface

Surface Plates

Grade AA / A / B precision surface plates in Black Granite and Cast Iron. Ultra-flat datum reference for height gauging, inspection jigs, and layout work.

Gr. AA / A / B≤5 µm flat

08 Grade K / 0 / 1

Ultimate length standards

Slip Gauge Blocks

Hardened and stabilised steel gauge blocks wrung together for ultra-precise reference dimensions. Grade K (master), Grade 0, and Grade 1 calibration sets.

±0.0001 mmGrade K/0/1

09 Smart Kit

Smart measurement systems

Digital Kits / Multi-Gauging

Integrated multi-channel gauging systems combining calipers, height gauges, dial indicators, and micrometers into a single SPC data-output unit for production QC.

USB / RS232SPC readyMulti-channel

Explore full measuring instruments range

What our client say

Happy With Customers & Clients

I feel very happy and be proud to connect with this industry. i presume this is a very productive and professional industry.i wish very good luck & success for this industry

We were struggling with long lead times for our equipment calibration with other vendors. Vertex Systems turned our UT sets around in 48 hours, fully certified. Their speed kept our project on schedule.

James R QA Manager, Oil & Gas Sector

Buying the equipment was easy, but the training is what set them apart. Their team came to our site and showed our technicians exactly how to configure the new Phased Array units for our specific welds

Ahmed K Site Supervisor, Construction

When our main X-ray crawler went down during a critical shutdown, Vertex arranged a rental replacement within a day. Their logistics team is a lifesaver.

James Contractor
